Callan Double Cylinder Deadbolt

Callan

Double Cylinder Function: Double cylinder deadbolts are keyed on both sides of the door and are only locked and unlocked via a key. Often times they are used on doors where glass is near the door that could be easily broken and the thumbturn on a standard single cylinder lock would be accessible. Caution: Double Cylinder locks can pose a safety hazard in times of emergency due to requiring a key to unlock. Please check local codes before installing.


Features:

  • Meets BHMA security grade 3 requirements
  • Made of durable zinc
  • Fully reversible handing for left or right handed applications
  • Designed for an easy one person installation
  • Comes standard with a round corner latch faceplate and 1" throw
  • Includes a limited lifetime warranty on mechanical parts and a five year warranty on finish


Specifications:

  • Backset: Adjustable 2-3/8" or 2-3/4"
  • Cross Bore: 2-1/8"
  • Edge Bore: 1"
  • Door Thickness: 1-3/8" to 1-3/4"
  • Handing: Reversible Left or Right
  • Diameter: 2-1/2"
  • Projection: 15/16"
  • Latch Faceplate: Round Corner
  • Cylinder: 5 Pin KW1
  • Concealed Screws: No
  • Material: Zinc
